Auxiliary light Lazer Linear 6 Elite+ - Straight / 23 cm / 69W / Ref. 17.5

The Linear 6 Elite Plus is a stylish, aerodynamic and elegant LED auxiliary light panel that offers amazing performance and an unprecedented white light for additional lights, as well as a yellow light intended for bad driving weather! Due to the unique design, this power pack is well suited for the front of even a smaller car, as well as for installation in tight spaces. The light is only 232 mm long, but it produces an amazing light output for its size. The manufacturer's stated maximum power for the light with only white light (more on the subject below) is a whopping 5100 lm, and when you add yellow light, the total power rises to 7100 lumens. The light beam in the Linear 6 Elite plus model is familiar from other Linear models, very flat and wide, which ensures that the road is illuminated from side to side. The manufacturer's range for the light is 300 m with white light in boost mode (@ 1 lux) and 311 m with a combination of yellow and white light (@ 1 lux)

What makes the light exceptional is its lighting properties: in addition to the traditional white light, Lazer's Plus series lights also have a yellow light, which is especially intended for driving in snow and rain, fog or dusty environments. The light produced by the yellow LEDs is directed slightly downward and laterally wider, which ensures the best possible visibility in low visibility conditions. Yellow light penetrates fog or e.g. snow dust better than bright white light, and in addition, it does not reflect and dazzle e.g. from the above-mentioned obstacles like white light. In total, the light has four operating modes: e-approved white light mode, white light boost power mode, yellow light only mode and combined yellow and white light power mode. The light also remembers the last used operating mode, and turns on the next time it is used in the same mode from which it was turned off. If the switch is pressed down for 2 seconds, the light switches directly to the e-approved power mode.

Note! The moderate reference figure (17.5) enables installation next to almost all standard high beams without removing the original lights from use!

Basic delivered content

• Lazer Linear 6 Elite+ (Plus)
• Anti-theft fasteners
• Connection and installation instructions
• End legs
• Note! The lamp does not include width-adjustable rail brackets. If you want, you can buy it separately here: Rail clamp, Lazer.

Delivery contents (2 pcs - Complete set)

• 2 x Basic delivery contents
• 2 x Rail Mount Lazer Center Mounting Kit
• Relay wiring kit Lazer, 12V (enables changing the operating mode directly from the cabin)
• Auxiliary light holder for registration plate (EU), 1 pc

Delivery contents (1 pc - Complete set / End fixing)

• Basic delivery content
• Relay wiring kit Lazer, 12V (enables changing the operating mode directly from the cabin)
• Additional light bracket Purelux Twisted Single Bracket

Technical information

• Brand and model: Lazer Linear 6 Elite+ (Plus)
• Purpose: As an additional light in cars / work machines
• LED: 12 x white, 6 x yellow
• Operating voltage: 9-32 V
• Reference number: 17.5
• Maximum power stated by the manufacturer: 69W
• Light output declared by the manufacturer: 5100 lm (white light in E-Boost mode), 7100 lm (white + yellow light)
• Range declared by the manufacturer: 300 m @ 1 lux / 600 m @ 0.25 lux
• Color temperature stated by the manufacturer: 5000 K
• Fastening: End feet
• Connector: AMP Superseal 3-pin
• Dimensions: 232 x 40 x 62 mm (Width/Height/Depth)
• Weight: 459 g
• Frame: Aluminum, black
• Other: Durable polycarbonate lens with lifetime warranty
• IP rating: IP67
• Approvals: E-Approval
• Country of manufacture: Great Britain
• Warranty: 60 months
