Auxiliary light Purelux 9110 UNLIMITED DRL - Round / 23 cm / 175W

• UNLIMITED = NO POWER LIMITATION!
• Narrow spotlight - long range!
• MEASURED LIGHT OUTPUT 12953 lm!
• HUGE 1016 m measured range!
• Orange and white parking light!
• Too powerful - NOT E-Approved

Purelux 9110 UNLIMITED DRL is an orange and white parking light version of its manufacturer's illegally powerful and very long-range 9110 UNLIMITED auxiliary light. This light offers maximum performance even for demanding drivers, and thanks to its amazing price/power ratio, it competes completely in its own class. Highly tuned electronics combined with the best Osram LEDs on the market enable a measured light output of almost 13,000 lumens, while the reflector optics optimized for these LEDs form a beam of light reaching up to 1016 meters (1 lux). The user experience is crowned by an eye-pleasing color temperature of 5500 Kelvin, optimized for vehicle use, which maximizes sharpness and accuracy. Due to the high power and spot-like beam, the light is not approved for road traffic use.

In addition to the tremendous power, the 9110 UNLIMITED DRL is equipped with a stylish, orange or white parking light, which is ingeniously placed in the center of the lamp. A bright, shining small line of light spreads the light directly onto the reflector surfaces of the lamp, whereby the light radiating from the reflectors illuminates practically the entire lens, creating an eye-catching effect that no one will notice. Simply stylish and unimaginably powerful, the 9110 UNLIMITED DRL is an excellent choice for anyone who needs an auxiliary  light with unlimited light output, maximum performance and an exceptionally far-reaching beam.

Note! The same lamp is also available with a white frame: Purelux 9110 UNLIMITED DRL White

There is also an applicable stone splash guard available for the light, which can be used to widen the light beam laterally. Protection available in white and yellow .

The 9110 UNLIMITED DRL differs from traditional auxiliary lights equipped with a combined light beam with its narrow light pattern, which enables the 9110 beam to reach over a kilometer (1 lux). In addition to the maximum range, the width of the light beam can also be easily increased by installing two or more lights in parallel, so that some of the lights can be directed to illuminate more of the edges of the road, and some can be directed straight ahead. With the power of more light, the range of the light beam also increases even more, which means that the landscape that opens up in front can be illuminated in a completely unprecedented way. The tremendous light output combined with a color temperature of 5500 Kelvin guarantees that the eyes will not be strained even during a long drive. In addition, the neutral color temperature of the lamp makes it easier to visualize terrain shapes and works better than cool shades even in bad weather conditions, such as fog and rain.

The 9110 UNLIMITED DRL's strong aluminum frame, sturdy construction and practically unbreakable Lexa polycarbonate lens ensure durability even in demanding conditions. The Purelux 9110 UNLIMITED DRL is dust and waterproof according to the IP68 protection rating, and it is also radio interference protected according to the R10 standard. All in all, this is a light that lasts even when going hard, like on the front of an SUV for example! In addition, it should be noted that the lamp is not E-approved, and for this reason we do not recommend installing the lamp in a vehicle intended for road traffic. The light is primarily intended only for off-road use and for closed tracks. Two-year (24 months) warranty!

Valostore's comment: "The best-selling auxiliary spotlight in its category has been updated! The 9110 DRL combines the wild performance known from the 9110, a really far-reaching spot light beam and a stylish two-color parking light. The version with orange and white parking light of this light cannon designed for off-road use makes it an even better option for those who want not only unlimited light output, but also elegant details. The parking light, realized in an exceptional way, illuminates practically the entire lens when it is on, which fits the image of this already rough auxiliary light perfectly!"

Basic delivery content (1 pc)

• Purelux 9110 UNLIMITED DRL
• Mounting leg
• Fastening accessories
• Anti-vibration pad

Delivery contents (2 pcs - Complete set)

• 2 x Basic delivery contents
• Auxiliary light holder for the EU license plate
• Relay wiring kit Purelux Pro Series 12V, HD DTP, (1 pc 2-output)
• Stabilizer, 2 pcs

Delivery contents (3 pcs - Complete set)

• 3 x Basic delivery contents
• Auxiliary light holder for EU license plate, 3 mm thick HD holder
• Relay wiring kit Purelux Pro Serie 12V, HD DTP, (1 pc 3-output)
• Stabilizer, 4 pcs

Delivery contents (4 pcs - Complete set)

• 4 x Basic delivery contents
• Auxiliary light stand Purelux HD, for 4 lights
• Relay wiring kit Purelux Pro Series 12V, HD DTP, (1 x 4-output)
• Stabilizer, 4 pcs

Delivery contents (4 pcs - Complete set WRC)

• 4 x Basic delivery contents
• Auxiliary light stand Purelux WRC, for 4 lights
• Relay wiring kit Purelux Pro Series 12V, HD DTP, (1 x 4-output)
• Stabilizer, 4 pcs

Delivery contents (5 pcs - Complete set WRC)

• 5 x Basic delivery contents
• Auxiliary light holder "Rally 5", 5 lights
• Relay wiring kit Purelux Pro Series 12V, HD DTP, (1 x 1-output, 1 x 4-output)
• Stabilizer, 6 pcs

Note! From 2 pcs - Complete Set you can buy the above set either as it is OR take in addition to it the XBB OBD Dongle & PowerUnit connection relay (see product options), with which the auxiliary light can also be connected to CAN-bus controlled lights. Instead of a traditional wiring harness, this set comes with a wiring harness with a Plug&Play-type place for the XBB relay (Relay wiring harness Purelux Dualrelay 12V, DTP). In short, the connection using the XBB relay is carried out by inserting the control device (OBD Dongle) into the OBD-II port of the car and placing the PowerUnit relay in a ready position in the supplied wiring harness next to the original relay of the wiring harness. The control device placed in the OBD port catches the high beam signal from the CAN bus and sends the information completely wirelessly to the relay in the wiring harness, which in turn controls the additional light according to this signal.

See the car models compatible with the XBB Dongle & PowerUnit connection relay here.

Technical information

• Brand and model: Purelux 9110 UNLIMITED DRL
• Purpose: As an auxiliary light in off-road vehicles / construction machines
• Operating voltage: 9-48V
• Reference number: - (NOT E-approved)
• Calculated power: 175 W
• Power consumption measured by Valostore: 13.08A @ 12V / 6.54A @ 24V
• Power measured by Valostore: 157 W
• Light output measured by Valostore: 12953 lm
• Range measured by Valostore: 1016 m @ 1 lux / 2032 m @ 0.25 lux
• Range with more lights, measured (@ 1 lux):
  • With two: 1437 m (@ 1 lux)
  • With three: 1760 m (@ 1 lux)
  • With four: 2032 m (@ 1 lux)
• Color temperature stated by the manufacturer: 5500 K
  • Measured by Valostore: 5575 K
• Mounting: Mounting base
• Connector: DTP-2
  • The parking lights + wires are separate
• Cable length: 500 mm
• Dimensions: 230 x 90 mm (Diameter/Depth)
• Height with foot: 235 mm
• Weight: 2500 g
• IP rating: IP68
• Approvals: EMC: ECE R10
• Warranty: 24 months
• Importer: Handshake.fi

Installation guide

Coupling

• DTP-2 connector: Auxiliary light connection
• White: White parking light
• Yellow: Orange parking light

You can find the manufacturer's connection and installation instructions by clicking here.
