Led bar Lazer Linear 6 Elite - Straight / 22 cm / 36W

The Lazer Linear 6 Elite is a slim, stylish and efficient led bar. Thanks to the unique design, this power pack fits well even on smaller cars and in tight spaces. The bar is e-marked and thus approved for use in traffic. The light pattern is a very precise and comprehensive combination light pattern, in other words there is a powerful spot with a long range in the center of the light, while the bar provides plenty of scattered light to the sides. Very good light bar for both road traffic and motorsport!

The bar's 12 efficient 3W LEDs combined with the modern reflector and lens technology provide a total of 4050 lumens of light flow and a range of 563 meters. The fine light pattern provides a lot of light focused exactly where you need it. The design means that you get a good range and at the same time a lot of scattered light that can be spread out towards the edges of the road.

Delivery content

• 1 x Lazer Linear 6 Elite LED bar
• Anti-theft brackets
• Manual for connection and assembly
• Mounting feet
• ATTENTION! Adjustable rail bracket not included.

Delivery content - Complete set (2 lights)

Contains everything needed for assembly and installation on most cars.

• 2 light bars Lazer Linear 6 Elite
• 2 rail mounts for extra light bar, Lazer
• Lazer relay wiring kit
• 1 pc Extra light holder for mounting on registration plate

Delivery content - Complete set (Side Mount)

ATTENTION! This package contains only one led bar.

• Standard Delivery Contents
• 1 pc Relay cable set Purelux AMP 2-pin Superseal, 12V
• Extra light holder Purelux Twisted Single Bracket
  • The extra light's side mounts are mounted on these mounts

Technical specification

• Brand and model: Lazer Linear 6 Elite
• Area of use: Complement the car's high beam
• Reference number: 17.5
• 12 x 3W LEDs
• Estimated power: 36 W

  • Measured by Valostore: 38,2 W
• Light output stated by the manufacturer: 4050 lm
  • Measured by Valostore: 2546 lm
• Range stated by the manufacturer: 563 m @ 0,25 lux / 282 m @ 1 lux
  • Measured by Valostore: 501 m @ 0,25 lux / 250 m @ 1 lux
• Color temperature stated by the manufacturer: 5000 K
  • Measured by Valostore: 5097 lm
• Frame: Black aluminium
• Durable polycarbonate lens with lifetime warranty
• Protection class: IP67
• Operating voltage: 9-32V
• Lifespan: approx. 50,000 hours
• Weight: 459 g
• Dimensions: 232 x 62 x 40 mm
• E-marked (approved for use in traffic)
• Country of manufacture: United Kingdom
• Warranty: 60 months
