Auxiliary light Purelux Black 760 - Round / 18 cm / 60W / Ref. 40

Purelux Black 760 is the smaller variant of the very popular Purelux 9120. Like the 9120, this variant is equipped with a great design, good performance and a two-tone parking light. The luminous flux of 6000 lumens specified by the manufacturer is controlled by the latest reflector and lens technology to an optimal light beam for road traffic. Deep reflectors create a very narrow, far-reaching cone of light that provides light far ahead, while the front reflectors spread the light of the more superficial diodes widely to illuminate the wall branch. In this way, an additional light creates a measured range of 403 meters (@1lux), which can be increased both in width and range by using more additional lights! Due to its size, the Black 760 is ideally suited for, for example, cars and vans.

Purelux Black 760's stylish dark optics give the auxiliary light a modern look, and make it a stylish part of the auxiliary lighting solution even for newer vehicles. The extra light's design is complemented by a stylish, X-shaped parking light, which can be lit either in the traditional way in white or in elegant orange. Just like other Purelux latest additional lights, the 760 is equipped with a frameless lens, so there is no threshold between the lens and the edge that collects snow, ice and dirt. In this way, it is easy to keep the auxiliary light clean and it is also easier to install high up with simple maintenance.

The impact-resistant aluminum frame, the practically unbreakable Lexa polycarbonate lens and enclosure class IP68 ensure that the extra light is perfectly adapted to the challenging and variable weather conditions in the Nordics. The fixture is shaped in such a way that the back of the auxiliary light does not come close to the back of the fixing iron. In this way, the 760 can be installed neatly even in places where there is not much extra space behind the attachment point. The extra light is suitable for both 12V and 24V systems. Two year (24 month) warranty!

Note! The lamp's power cord and wiring harness have a DT2 connector. When choosing a complete package, a DT4 - DT2 adapter cable is included that fits between the additional light and the relay cable set. The parking light is not automatically made to fit the relay harness and therefore must be wired yourself.

Contents (1 pc)

• Purelux Black 760
• Mounting foot
• Power cord with DT-2 plug

Contents (2 pcs)

• Purelux Black 760, 2 pcs
• Mounting feet, 2 pcs
• Power cord with DT2 connector, 2 pcs

Contents (2 pcs - Complete package)

• Purelux Black 760, 2 pcs
• Extra light holder for EU license plate, Purelux, for 2 extra lights
• Relay cable set Purelux Pro Series 12V, 2 outputs

Contents (3 pcs - Complete package)

• Purelux Black 760, 3 pcs
• Extra light holder for EU license plate, Purelux, for 3 extra lights
• Relay cable set Purelux Pro Series 12V, 3 outputs

Contents (4 pcs - Complete package)

• Purelux Black 760, 4 pcs
• Extra light holder for EU license plate Purelux HD, for 4 extra lights
• Relay cable set Purelux Pro Series 12V, 4 outputs

Technical specification

• Make and model: Extra light Purelux Black 760
• Area of use: As additional light in cars/work machines
• LED: 12 x 5W OSRAM
• Operating voltage: 9-30 V
• Reference number: 40
• Manufacturer's reported current consumption: 3.75A @ 12V
• Estimated power: 60 W
• Manufacturer's reported power: 60 W

  • Measured by Valostore: 41.7 W
• Manufacturer's reported luminous flux: 6000 lm
• Manufacturer's reported range: 469 m @ 1 lux
  • Measured by Valostore: 806 m @ 0.25 lux / 403 m @ 1 lux
• Manufacturer's reported color temperature: 5700 K
  • Measured by Valostore: 5278 K
• Mounting: Mounting foot
• Contact: Deutch DT-2
• Dimensions: 177.2 x 192 x 74.7 mm (Width / Height / Depth)
• Weight: 1078 g
• Protection class: IP68
• Approvals: EMC: ECE R10, R148, R149
• Warranty: 24 months
• Importer: Handshake Finland Oy

Quick guide

Coupling

• DT-2 connector: Additional light connection
• White: White parking light
• Yellow: Orange parking light
