Auxiliary light Lazer Triple-R 1000 GEN2 Double Beacon - Straight / 41 cm / 88W

Lazer Triple-R 1000 Gen2 Double Beacon an additional light that uses the latest LED and reflector technology, equipped with a spectacular orange or white parking light. In addition to its function as an additional light, the Double Beacon model has an integrated strobe light function with 16 operating modes, so the additional light also functions as a strobe light. In this way, a flash light is not necessarily needed, but a ramp takes care of both functions. The integrated flashing light function is approved for traffic use according to the ECE R65 class. The Triple-R 1000 Gen2 is a high-performance auxiliary light whose point-like light cone is well suited for both road traffic and off-road use. According to the manufacturer, the auxiliary light produces a huge luminous flux of 9240 lm and a range of 612 m (1 lux), which is an amazing performance for a ramp of this size class.

The ramp's subtle design also blends into the front of modern vehicles. The Triple-R 1000 Gen2 Double Beacon also has a patented E-BOOST technology that makes it possible to use the lamp with less power in road traffic (E9) and with higher power outside normal European road traffic. As we in Sweden do not comply with these requirements, it is possible to use the extra light with boost function for road traffic. The extra light's aluminum structure, polycarbonate lens with a lifetime guarantee (against crushing damage) and an advanced Gore-Tex seal (which prevents moisture from entering the ramp) ensure that the extra light's functionality and durability are maintained even under the most demanding conditions. The perfect choice for both heavy vehicles for traffic use, as well as for e.g. work machines and passenger cars.

The extra light's narrow light cone provides a very long range and ensures good visibility. The additional light's reflectors are round, just like the other additional lights in the Triple-R series, so the height of the light image is also sufficient for dense terrain or when driving off-road. In addition, the panel's 5000K color temperature reduces strain on the eyes and makes use pleasant even during longer periods of use. The flash function can be synchronized with several lights, so that all lights flash at the same rate. The flash function has a total of 16 operating modes, so that a suitable mode is always available depending on the situation.

Note! The extra light's parking lights in orange or white are not ECE R7-approved, but this does not affect use in Sweden.

Content

• Lazer Triple-R 1000 GEN2 Double Beacon
• Adjustable rail brackets, 2 pcs
• Connection and installation instructions

Contents (1pc - Complete package)

• Content (see above)
• Lazer relay wiring kit
• Extra light holder Purelux Single Bracket
  • Note! The lamp has a 6-pin connector, which does not fit directly into the relay kit. You therefore have to make the connections for additional lights, parking lights and warning lights yourself.

Technical specification (E-Boost / E-Mark Mode)

• Brand and model: Extra light Lazer Triple-R 1000 GEN2 Double Beacon - Straight / 41 cm / 88W
• Area of use: As additional light/warning light for cars/work machines
• Operating voltage: 9-32V
• Current consumption: 6.1 A / 1.2 A (@14.4 V)
• Power: 88W / 17.6W
• Reference number: N/A / 12.5
• Manufacturer's reported luminous flux: 9240 lm / 1848 lm
• Manufacturer's reported range: 612 m / 274 m (@ 1 lux)
• Parking lights: White or orange
• Color temperature: 5000 K
• Lifespan: approx. 50,000 hours
• Materials: Aluminum, polycarbonate lens
• Protection class: IP67
• Dimensions: 410 x 73 x 105 mm (Width x Height x Depth)
• Height with foot: 103 mm
• Weight: 1700 g
• Connector: AMP 6-pin
• Country of manufacture: United Kingdom
• Approvals: ECE R112, ECE R65 (ECE R7 / White parking light)
• Warranty: 60 months
