Led bar Purelux Black Boost S200 Gen3 - Straight / 20 cm / 60W / Ref. 25

The Purelux Black Boost S200 Gen3 is part of its manufacturer's updated Black auxiliary light series, which brings top quality and hard performance to an affordable price range. The S200 Gen3 has the familiar two different power modes from the previous version, a wide combination beam and, of course, an edgy appearance. As a novelty, a two-color (orange or white) parking light has been introduced, and switching between power modes has been made even easier. Black Boost S200 is now even more stylish and at the same time more user-friendly! Thanks to two different power modes, the panel can be used with a selection integrated into the user interface (see more below) to switch on either the more moderate power mode approved for road traffic, or the more powerful PowerBoost® mode designed for off-road use. In the power mode approved for road traffic, the S200 Gen3 offers a measured light output of 1747 lumens, and when unlimited PowerBoost® is switched on, the measured light output from the panel rises to up to 3726 lumens with a measured range of 403 meters @ 1 lux, which is an impressive performance for a panel of this size.

Note! You can clearly see the difference between Purelux PowerBoost® and road traffic mode - PowerBoost® mode is significantly more efficient and should not be used when driving in normal road traffic, only off-road.

The spotlight of the S200 Gen3 combines elements optimized for road traffic: in the middle of the light pattern there is a bright and clear main spot offering a long range, with a wide beam opening laterally from the side of the road to the side - right from the bow. The light beam is shaped flat with the help of reflectors, so that the light is not unnecessarily directed in front of the bow or at the tops of the trees. The color temperature of the panel is 5700 Kelvin. The small size of the S200 Gen3 makes it an excellent choice for e.g. for mask installations and shield installations where you want to put two small panels side by side.

The light has a black frame and dark optics, which is already evident in the name, which give the panel an elegant and modern look. The dark optics also continue in the parking light, thanks to which the parking light bar running in the middle of the lens stands out from the light only when it is on, so the light is stylish both when switched on and off. The frames of the Black series panels are made of powder-coated and durable aluminum alloy and the lenses of virtually unbreakable polycarbonate, and the lights are also fully protected against water and dust according to the IP69K rating. The frameless front part of the lights prevents the accumulation of snow, ice and dirt in front of the lens, thanks to which the light beam is not obscured as easily as with additional lights equipped with a frame.

Installation is easy by using the DT-2 connector on the power cord of the light, and the width-adjustable lower legs and end legs that come with the package provide plenty of mounting options. Wide operating voltage (9-32V) enables installation in both 12V and 24V systems. The lamp is protected against radio interference according to the ECE R10 standard. Two-year (24 months) warranty!

Basic delivery content (1 pc / 2 pc)

• Purelux Black Boost S200 Gen3
• 2 x Width-adjustable lower legs
• 2 x End feet
• Power cable counterpart
• Connection and installation instructions (FI/SE/NO/DK/EN)

Contents of delivery (1 pc - Complete set Bottom bracket)

• Basic delivery contents
• Auxiliary light bracket Purelux Single Bracket, 2 pcs.
• Set of relay wires Purelux Pro Serie 12V, DT-2 (1 output)

Delivery contents (1 pc - Complete set End fixing)

• Basic delivery content
• Auxiliary light bracket Purelux Twisted Single Bracket, 2 pcs.
• Set of relay wires Purelux Pro Serie 12V, DT-2 (1 output)

Delivery content (2 pcs - Complete set Bottom bracket)

• 2 x Basic delivery contents
• Auxiliary light holder for EU plate, Purelux
• Set of relay wires Purelux Pro Serie 12V, DT-2 (2 outputs)

Specifications

• Brand and model: Purelux Black Boost S200 Gen3
• Purpose: As an additional light in cars / Off-Road vehicles / work machines
• LED: Osram
• Operating voltage: 9-32 V
• Reference number: 25
• Calculated power: 60 W
• Power consumption measured by Valostore
  • Purelux PowerBoost®: 4.01A @ 12V / 0.95A @ 24V
  • Road mode: 1.9A @ 12V / 0.95A @ 24V
• Power measured by Valostore:
  • Purelux PowerBoost®: 48.2 W @ 24V
  • Road mode: 22.8 W @ 24V
• Light output declared by the manufacturer: 5040 lm (Purelux PowerBoost®)
  • Measured by Valostore: 3726 lm (Purelux PowerBoost®)
  • Measured by Valostore: 1747 lm (Traffic condition)
• Range measured by Valostore: 403 m @ 1 lux / 806 m @ 0.25 lux (Purelux PowerBoost®)
• Range measured by Valostore: 288 m @ 1 lux / 576 m @ 0.25 lux (Traffic mode)
• Color temperature stated by the manufacturer: 5700 K
  • Measured by Valostore: 5818 K
• Fastening: End legs, width-adjustable lower legs
• Connector: DT-2
• Cable length: 50 cm
• Dimensions: 204 x 70 x 67 mm (Width x Height x Depth)
  • Height with end legs: 86 mm
  • Height with lower legs: 89 mm
• Weight: 880 g
• IP rating: IP69K
• Approvals: ECE: R10, R112*
  • *Road traffic approval does not apply to PowerBoost® mode
• Warranty: 24 months
• Importer: Handshake.fi

Installation guide

Changing the power mode with UI technology: The first time the lamp is used, it lights up in the E-approved mode. Change the power mode by using the auxiliary light on for at least 2 seconds, then flash high beam twice to change the power mode. Repeat to change power mode again.

You can find the manufacturer's connection and installation instructions (FI/SE/NO/DK/EN) by clicking here.
