Marker light Purelux Spectre 12X

The Purelux Spectre 12X is a light that fits perfectly as a position light / side marker. Thanks to the fact that it can be used with white, red or orange light, it is very versatile and suitable for a variety of applications. The simple connection via a separate cable means that the same lamp is suitable for mounting virtually anywhere on your vehicle because you can easily choose which color you want the Spectre 12X to shine in. The Purelux Spectre 12X is especially suitable for heavy vehicles, work machines, trucks and vans, or other vehicles where lighting is the focus! The black circuit board that can be glimpsed through the clear lens makes it blend in nicely even when it's not lit. The modern look and elegant design as well as the good distribution of the light make the Purelux Spectre 12X perfect for those who want to draw attention to you on the roads!

Purelux Spectre 12X is E-approved according to the ECE R148 standard, which includes approval for, for example, flashing lights, brake lights, turn signals, side markers and position lights.

The Spectre 12X is dust and waterproof according to protection class IP67, so no weather and traffic conditions limit the use of this extreme light. It is not only completely dustproof, but also resistant to temporary immersion, which means that it can easily withstand heavy rain or a vehicle wash. The lens is made of very durable polycarbonate.

The low and compact design enables spectacular surface installation in virtually any vehicle, and the wide operating voltage range (10-30 V) enables installation in both 12V and 24V systems. The lamp comes with an installation background and two screws for attachment.

Tip! If you want the lamp to also function as a warning flasher, we recommend combining the Spectre 12X with this: Purelux Strobe Controller

Content

• Purelux Spectre 12X
• Sealing plate
• Mounting screws

Technical specification

• Brand and model: Purelux Spectre 12X
• Area of use: As side markers/position lights in vehicles or work machines
• Operating voltage: 10-30 V (DC)
• LED: 12 x 0.5W
• Light color: White, orange or red
• Power: 6 W
• Dimensions: 102 x 25 x 12 mm (W x H x D)
  • CC dimensions: 85 mm (measurement between attachment points)
• Power cable length: 500 mm
• Weight: 40 g
• Protection class: IP67
• Approvals: SAE, ECE R148
• Warranty: 24 months

Coupling

• Red: Red Light (+)
• Yellow: Orange light (+)
• White: White light (+)
• Black: Ground (-)

You can find the manufacturer's installation instructions here (opens in a new window).
