Auxiliary light Purelux Panther Alpha 20, 20W, Spot

Purelux Panther Alpha is a spectacular new generation work light series designed for challenging conditions. Alpha lamps bring something completely new to the market with a unique design and a two-color parking/extreme light. Unlike other Alpha series lights, the Alpha 20 Spot is also equipped with road traffic approval, which means it can be used as an additional light in any vehicle. The lamp produces a light output of 1500 lumens and the range of the light beam is measured up to 264 m @ 1 lux. The really compact and low body Panther Alpha 20, as its name suggests, forms a spot-like beam of light, which together with the R149 road traffic approval makes it an excellent light to install in front of the vehicle. In terms of size and power, it is a good choice for e.g. for ATVs, motorcycles, smaller work machines and vehicles, as well as practically all such applications where a really small size and long-range beam are required from the light.

As the name suggests, the light beam of the Alpha 20 Spot is very spot-like, thanks to which the range of the beam has been maximized despite the light's small size. Thanks to the advanced reflector technology, the light pattern is softly delimited in the vertical direction, so that all the light output can be directed straight ahead. In addition, the vertically limited light beam reduces glare, which is a desirable feature especially for work use. In addition to the spot light beam, the Panther Alpha 20 Spot is equipped with a neutral 5000K color temperature, which is the optimal choice for both road traffic use and working light. The 5000K color temperature maximizes sharpness and accuracy, making it much easier to detect terrain shapes and obstacles.

In addition to excellent lighting properties, Panther Alpha lights are also extremely stylish, and their unique design language is completely different from other work lights on the market. The great design combined with the dark profile and the orange or white parking light at the bottom of the frameless lens make the Alpha lights a unique addition to any vehicle. In addition, these lamps have been created to withstand challenging conditions, as evidenced by e.g. their highest possible tightness rating (IP69K), a frame made of durable aluminum and a lens made of practically unbreakable polycarbonate. The lights also have an intelligent temperature regulation system, which prevents overheating even during long working days and guarantees safe and worry-free working even during seasonal work. Wide operating voltage (9-36V) enables installation in both 12V and 24V systems.

The lights of the Panther Alpha series have a DT-4 connector already integrated into the power cord, which makes installation easier. The counterpart of the connector is also supplied. Panther Alpha 20 is protected against radio interference according to R10 classifications. Three-year (36 months) warranty!

NOTE! If you want the parking light to flash, it can be done with a separate flasher relay: Purelux Strobe Controller.

Panther Alpha series models

• Purelux Panther Alpha 20, 20W, Wide
• Purelux Panther Alpha 20, 20W, Spot
• Purelux Panther Alpha 30, 30W, Wide
• Purelux Panther Alpha 60, 60W, Wide
• Purelux Panther Alpha 60, 60W, Spot
• Purelux Panther Alpha 90, 90W, Wide

Delivery content

• Purelux Panther Alpha 20 Spot
• Sturdy mounting leg
• Fixing bolt
• Power cable with DT-4 connector, 50 cm
• The counterpart of the connector
• Connection and installation instructions (EN, FI, SE, NO, DK)

Specifications

• Brand and model: Purelux Panther Alpha 20 Spot
• Purpose: As a work light / additional light in vehicles or work machines
• Reference number: 17.5
• Operating voltage: 9-38V
• Power consumption measured by Valostore
  • Work light: 0.79A @ 24V
  • Parking light: 0.23A @ 24V
• Theoretical power declared by the manufacturer: 20 W
• Power measured by Valostore
  • Work light: 19 W
  • Parking light: 5.6 W
• Light output stated by the manufacturer: 1500 lm
  • Measured by Valostore: 1390 lm
• Range measured by Valostore: 264 m @ 1 lux / 528 m @ 0.25 lux
• Color temperature stated by the manufacturer: 5000 K
  • Measured by Valostore: 5066 K
• Mounting: Mounting base
• Connector: DT-4
• Cable length: 50 cm
• Dimensions: 96 x 45 x 50 mm (Width x Height x Depth)
  • Height with foot: 71 mm
• Weight: 320 g
• IP rating: IP69K
• Operating temperature: -40°C to +60°C
• Approvals: EMC: ECE R10, R148, R149, CE, RoHS
• Warranty: 36 months

Installation guide

You can find the manufacturer's connection and installation instructions (FI/SE/NO/DK/EN) by clicking here.
