Led bar Purelux Panther S800 Gen3 - Straight / 78 cm / 324W / Ref. 50

PRODUCT DESCRIPTION - DELIVERY CONTENTS - TECHNICAL DATA

• PowerBoost® technology
• Unfathomable size-performance ratio!
• A long-range combination beam
• 21991 lumens, 729 meters (@ 1 lux)
• Pleasant 5000K color temperature
• Stylish two-color parking light
• Frameless Lexa polycarbonate lens
• Easy attachment with end or bottom legs

The Purelux Panther S800 Gen3 is an extremely powerful led bar that represents the top of its class in terms of performance and light beam as well as appearance. This light has two different power modes, thanks to which you can switch on either the more moderate power mode approved for road traffic or the PowerBoost® mode that releases all the light power. The unlimited PowerBoost® mode raises the driving experience on sections that require maximum light output to a completely new level, as the light output is measured up to 21991 lumens and the range up to 729 meters (@ 1 lux). The power mode can be changed easily by pressing the button on the body, so there is no need to make laborious connections! When the untamed performance of the Panther is combined with a great design and one of the best combination headlights on the market, it goes without saying why it jumps to the top of its size class in every area!

"Notorious Panther performance"

Unlike usual, you don't need to connect or disconnect any extra wires to activate the lamp's different power modes, instead switching between PowerBoost® and road mode is unprecedentedly easy by pressing the button at the end of the lamp. The last used power mode remains in the lamp's "memory", and thus there is no need, for example, in road traffic use, to ensure that the lamp always turns on at maximum power, when the power is turned off in between and the car starts moving again.

Note! You can clearly see the difference between Purelux PowerBoost® and road traffic mode - PowerBoost mode is significantly more efficient and should not be used when driving in normal road traffic, only off-road.

The Panther S800's beam consists of a rectangular wide main beam, which is the perfect combination of both range and width. The beam opens right from the bow and illuminates all the way from curb to curb, while the brighter main spot in the middle of the beam directs the light far forward. In the vertical direction, the beam is softly delimited, making it optimal especially for bow installations. However, despite the vertically limited beam, there is still plenty of light for driving on hilly terrain and for roof installations.

The difference between the curved and straight Panther is in the beam: both models have enough beam to illuminate the entire road from side to side, but the curved panel has a main beam that is about 50% wider and slightly more vertically limited than the straight model. The area effectively illuminated is therefore wider in the curved design, while the straight design maximises the beam's range. If the aim is to find the widest possible light pattern, the curved panel is the right choice, while if a little more range is desired, the straight panel is the right choice. Because the curved design has a straighter beam from the top and bottom, it is a slightly better option for really low installations.

In addition to the precisely finished light beam, a feature that significantly improves the driving experience is the light's neutral color temperature of 5000 Kelvin. Neutral color temperature is optimal for road traffic, as it facilitates the observation of terrain shapes and obstacles, and it does not distort the color of objects. In addition, it dazzles less cool tones from e.g. snow cover or in fog and rain, and reduces the strain on the eyes. The 5000K color temperature perfectly suits newer cars with LED or Xenon lights as standard, and brings the desired brightness and sharpness even alongside traditional halogen lights.

In addition to excellent lighting properties, the Panther S800 Gen3 has been created to withstand the stresses of the environment, as evidenced by e.g. the highest possible tightness rating (IP69K), a practically unbreakable Lexa polycarbonate lens, a frame made of strong aluminum and a special coating that guarantees the panel excellent durability against UV radiation, corrosion, chemicals and changing weather conditions. In addition to protection, the high-quality coating also gives the panel body a slightly shiny surface that exudes dignity, quality and style. The wonderful overall look is crowned by the black fastening screws and dark optics, which have also been brought to the parking light in a modern way to guarantee elegance even when the panel is off.

"Purelux Panther series is made with uncompromising quality and top of the line performance. Every feature is finely tuned to fit any type of situation and vehicle. Don't hesitate, ride with the Panther!” - Purelux

The light comes with both the traditional end legs and the width-adjustable rail mounts below the lamp. The installation is made easier by the ready-made attachment points for support irons in the panel frame (the use of support irons is not necessary, if the installation can otherwise be carried out securely). The wide operating voltage range (9-36V) enables installation in both 12V and 24V systems. In addition, the lamp is protected against radio interference in accordance with the ECE R10 standard. Two-year (24 months) warranty!

Valostore's comment on the Purelux Panther Gen3 series: "Purelux's Panther series is its manufacturer's most popular product family of all time, and for no reason. This auxiliary light series combines a spectacular appearance, fierce performance and one of the best combination light beams on the market. Panthers have always had all the pieces in place, but the latest Gen3 update dark optics have been introduced to the parking light, the use of the PowerBoost button has been made easier and the lamp body has been treated with a high-quality special coating, which not only protects better than before, but also gives the lights an elegant, slightly shiny surface !"

The Purelux Panther series includes both straight and curved auxiliary lights. You can get to know the other models from the links below:

Straight models

• Purelux Panther S300 Gen3
• Purelux Panther S540 Gen3
• Purelux Panther S540 Gen3 White
• Purelux Panther S800 Gen3
• Purelux Panther S1050 Gen3

Curved models

• Purelux Panther C540
• Purelux Panther C800
• Purelux Panther C1050

Basic delivery content

• Purelux Panther S800 Gen3
• 2 x Width-adjustable lower legs
• 2 x End feet
• Connection and installation instructions (FI/SE/NO/DK/EN)

Delivery contents (1 pc - Complete set)

• Basic delivery content
• Universal auxiliary light holder for EU plate, Purelux
• Adjustable stabilizer for auxiliary lights, Purelux Stabilizer (2pcs)
• Wiring harness with relay Purelux HD, 12V

  • Note! Due to the high power, there are no connectors on the auxiliary light or relay cable kit; you must make the connections yourself.

Specifications

• Brand and model: Purelux Panther S800 Gen3
• Purpose: As an auxiliary light in cars / Off-Road vehicles / work machines
• LED: 54 x 6W
• Operating voltage: 9-36 V (DC)
• Reference number: 50
• Calculated power: 324 W
• Power consumption measured by Valostore
  • Purelux PowerBoost®: 12A @ 24V
  • Road mode: 2.41A @ 24V
• Power measured by Valostore
  • Purelux PowerBoost®: 288W @ 24V
  • Road mode: 58W @ 24V
  • Parking light: 6 W
• Light output declared by the manufacturer: 23300 lm (Purelux PowerBoost®)
  • Measured by Valostore: 21991 lm (Purelux PowerBoost®)
  • Measured by Valostore: 5830 lm (Road traffic mode)
• Range measured by Valostore: 729 m @ 1 lux / 1458 m @ 0.25 lux (Purelux PowerBoost®)
• Range measured by Valostore: 379 m @ 1 lux / 758 m @ 0.25 lux (Traffic mode)
• Color temperature stated by the manufacturer: 5000 K
  • Measured by Valostore: 4899 K
• Fastening: End legs, width-adjustable lower legs
• Connector: Straight wires, no connector
• Cable length: 100 cm
• Dimensions: 783 x 66 x 70 mm (Width x Height x Depth)
  • Height with end legs: 78 mm
  • Height with lower legs: 81.5 mm
• Weight: 3445 g
• IP rating: IP69K
• Approvals: ECE R10, R148, R149*
  • *Road traffic approval does not apply to the Purelux PowerBoost® mode
• Other: The panel has ready-made places for stabilizers
• Warranty: 24 months
• Importer: Handshake.fi

Installation guide

You can find the manufacturer's connection and installation instructions (FI/SE/NO/DK/EN) by clicking here.
